ETICHETTATRICI MANUALI / semiautomatiche

VENUS
for desk.

Semi-automatic system for applying labels on flat or oval products. The system is ideal for products that require precision application. The application is done through a pneumatic cylinder with a suction plate shaped to label size at the base. Once the product has been placed on the template, the label is sucked onto the plate (via the vacuum) through a manual start, and placed on product at the end of cylinder run.

optional

KNOW US BETTER

VENUS FOR DESK IN ACTION.

Automatic self-adhesive label applicators to be combined with production lines, ideal for the application of top, bottom and side self-adhesive labels.

download brochure

SHOWS HOW THE MACHINE WORKS

How does it works ?

watch the video

TECHNICAL INFO.

Venus for desk

table data
Speed	5 to 15 m/min
Max. label width	100/140 mm
Min. label width	10 mm
Max. label length	500 mm (other sizes on request)
Engine type	step/step
Stop label reader	fork photocell or microswitch only for transparent labels
Max. label spool diameter	300 mm
Suction plate shaped to fit label	da 50mm o 200mm

table data
Suction plate shaped to fit label	shaped label or fit
Pressure gauge for regulating compressed air	6/8 Bar
pneumatic material	FESTO
Label spool core diameter	between 38 mm and 76 mm
Tolerance for applying labels at top speed	0,3 mm
Microprocessor-controlled electronic digital control unit and display	it allows perfect adjustment of label progression, without resorting to mechanical movements of the photocell

table data
Available adjustments	dispensing speed, application delay, label air blow time adjustment, label suction time
Basement	The whole system is placed on an aluminum crankcase with 4 adjustable feet
Weight	20 Kg
Max. overall dimensions	850 mm x 500 mm x 210 mm
Power supply	220 o 110 V 50/60 Hz
Operating temperature	between +40°C and 0°C
